Acson A5CK20A User Manual

MODEL: A5LC 25/28C
No Description No Description
1 Assy, Base Pan 11 Front Panel, Left
2 Assy, Outdoor Coil 12 Service Panel
3 Motor Bracket 13 Terminal Cover Panel
4 Fan Motor 14 Assy, Control Panel
5 Fan Blade 15 Top Panel
6 Valve Bracket 16 Assy, Front Grille
7 Assy, Flare Valve 3 Ways 17 Plastic Handle, Side
8 Assy, Flare Valve 2 Ways (ALC/A5LC25C) 18 Assy, Valve Cover
Assy, Flare Valve 3 Ways (ALC/A5LC28C) 19 Assy, Cap Tube
9 Back Panel, Right 20 Partition
10 Compressor 21 Plastic, Handle, Front
16
