MODEL: A5LC 20C
No Description No Description
1 Assy, Base Pan 11 Front Panel, Left
2 Assy, Outdoor Coil 12 Service Panel
3 Motor Bracket 13 Terminal Cover Panel
4 Fan Motor 14 Assy, Control Panel
5 Fan Blade 15 Top Panel
6 Valve Bracket 16 Assy, Front Grille
7 Assy, Flare Valve 3 Ways 17 Plastic Handle
8 Assy, Flare Valve 2 Ways 18 Assy, Valve Cover
9 Back Panel, Right 19 Assy, Cap Tube
10 Compressor 20 Partition
15
