19
MODEL: A5LC 35/40/50C/CR
No Description No Description
1 Assy, Base Pan 9 Top Panel
2 Assy, Flare Valve 10 Assy, Coil
3 Assy, Flare Valve 11 Bracket, Fan Motor
4 Panel, Partition 12 Side Panel, Left
5 Compressor 13 Fan Motor
6 Service Panel 14 Fan Blade
7 Accumulator 15 Assy, Front Pnel
8 Back Panel 16 Plate, Flare Valve
To Next Page
