ASCON Service Guide Book
69
Inverter-Y Model
Indoor Series
Model Board Handset
A5WMY 10/15/20/25 JR G18
A5CKY 10/15/20CR
G18
A5CKY 20/25/28/40/50 ER
G18/ GS02
A5CEY 62 CR
GS02
A5CEY 20/25/28/40/50 ER
G18/ GS02
A5CCY 20/25/28/38/50/60 CR
G18/ GS02
LED Indicator Lights: Normal Operation and Fault Conditions for Heat Pump Unit
Operation / Faulty Indication
Cooling mode
Heating mode
Auto mode in heating operation
Auto mode in cooling operation
Time Off (when unit is on)
Time On (when unit is off)
Sleep mode on
Fan mode on
Dry Mode on
Green
Defrost operation
Error indication
COOL/HEAT
(GREEN/RED)
Green
Red
Red
Green
Red
Green
Green
ON Blinking
