Acson A5LC User Manual

ASCON Service Guide Book
88
Appendix
Resistance – Temperature Characteristics
Type DTN-C1 03F3H-OYL 1128, 1148, 1158
Material Name 3H
Resistance R25=10.000k Ω + 1.0% - 1.0%
B Value B25/30=3450K + 1.0% - 1.0%
t°C Rmin (k Ω ) Rnom (k Ω ) Rmax (k Ω ) t°C Rmin (k Ω ) Rnom (k Ω ) Rmax (k Ω )
-10 4.42E+01 4.53E+01 4.65E+01
-8 4.02E+01 4.12E+01 4.22E+01 42 5.28E+00 5.37E+00 5.45E+00
-6 3.66E+01 3.74E+01 3.83E+01 44 4.92E+00 5.01E+00 5.09E+00
-4 3.33E+01 3.41E+01 3.49E+01 46 4.59E+00 4.67E+00 4.76E+00
-2 3.04E+01 3.11E+01 3.18E+01 48 4.29E+00 4.37E+00 4.42E+00
0 2.78E+01 2.84E+01 2.90E+01 50 4.01E+00 4.09E+00 4.16E+00
2 2.54E+01 2.59E+01 2.65E+01 52 3.75E+00 3.82E+00 3.90E+00
4 2.33E+01 2.37E+01 2.42E+01 54 3.51E+00 3.58E+00 3.65E+00
6 2.14E+01 2.18E+01 2.21E+01 56 3.29E+00 3.36E+00 3.43E+00
8 1.96E+01 2.00E+01 2.03E+01 58 3.08E+00 3.15E+00 3.22E+00
10 1.80E+01 1.83E+01 1.86E+01 60 2.89E+00 2.96E+00 3.01E+00
12 1.66E+01 1.69E+01 1.71E+01 62 2.71E+00 2.78E+00 2.84E+00
14 1.53E+01 1.55E+01 1.57E+01 64 2.55E+00 2.61E+00 2.67E+00
16 1.41E+01 1.43E+01 1.45E+01 66 2.40E+00 2.45E+00 2.51E+00
18 1.30E+01 1.32E+01 1.33E+01 68 2.25E+00 2.31E+00 2.37E+00
20 1.20E+01 1.22E+01 1.23E+01 70 2.12E+00 2.17E+00 2.23E+00
22 1.11E+01 1.12E+01 1.14E+01 72 2.00E+00 2.05E+00 2.10E+00
24 1.03E+01 1.04E+01 1.05E+01 74 1.88E+00 1.93E+00 1.98E+00
26 9.52E+00 9.62E+00 9.72E+00 76 1.77E+00 1.82E+00 1.87E+00
28 8.82E+00 8.92E+00 9.02E+00 78 1.67E+00 1.72E+00 1.77E+00
30 8.17E+00 8.27E+00 8.37E+00 80 1.58E+00 1.62E+00 1.67E+00
32 7.58E+00 7.68E+00 7.78E+00 82 1.49E+00 1.53E+00 1.58E+00
34 7.04E+00 7.14E+00 7.23E+00 84 1.41E+00 1.45E+00 1.49E+00
36 6.54E+00 6.64E+00 6.73E+00 86 1.33E+00 1.37E+00 1.41E+00
38 6.09E+00 6.18E+00 6.27E+00 88 1.26E+00 1.30E+00 1.34E+00
40 5.67E+00 5.75E+00 5.84E+00 90 1.19E+00 1.23E+00 1.27E+00

Acson A5LC Specifications

General

Brand	Acson
Model	A5LC
Category	Air Conditioner
Language	English
