Engineering & Physical Data A5LCY_(i)
Engineering & Physical Data
MODEL: A5WMY-LR
MODEL
INDOOR UNIT A5WMY10JR A5WMY15JR A5WMY20JR A5WMY25JR
OUTDOOR UNIT A5LCY10DR A5LCY15DR A5LCY20CR A5LCY25CR
NOMINAL COOLING CAPACITY
Btu/h 8872 (3754 - 11260) 11942 (4436 - 13307) 18600 (6415 - 21155) 21200 (6824 - 22178)
W 2600 (1100 - 3300) 3500 (1300 - 3900) 5450 (1880 - 6200) 6210 (2000 - 6500)
NOMINAL HEATING CAPACITY
Btu/h 10236 (3412 - 13990) 12966 (3412 - 15696) 19176 (4504 - 22520) 21837 (5323 - 24226)
W 3000 (1000 - 4100) 3800 (1000 - 4600) 5620 (1320 - 6600) 6400 (1560 - 7100)
NOMINAL TOTAL INPUT POWER (COOLING) W 760 1050 1460 1880
NOMINAL TOTAL INPUT POWER (HEATING) W 828 1050 1500 1710
NOMINAL RUNNING CURRENT (COOLING) A 4.10 5.00 6.53 8.45
NOMINAL RUNNING CURRENT (HEATING) A 4.00 4.90 6.72 7.63
EER W/W 3.42 3.33 3.73 3.30
COP W/W 3.62 3.62 3.75 3.74
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR EXV
REFRIGERANT CHARGE kg 0.75 1.10 1.45 1.50
POWER SOURCE V/Ph/Hz 220~240 /1/ 50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE AUTO LOUVER (UP & DOWN) & GRILLE (LEFT & RIGHT)
OPERATION WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
TURBO l/s / CFM 178 / 378 185 / 392 273 / 578 332 / 703
HIGH l/s / CFM 153 / 324 160 / 337 250 / 529 309 / 654
MEDIUM l/s / CFM 119 / 252 124 / 262 222 / 471 276 / 585
LOW l/s / CFM 93 / 197 101 / 213 197 / 418 239 / 507
QUIET l/s / CFM 86 / 182 177 / 374 206 / 437
SOUND PRESSURE LEVEL (SH/H/M/L/SL) dBA 41 / 40 / 34 / 29 / 25 42 / 41 / 34 / 30 / 28 44 / 42 / 39 / 36 / 33 46 / 44 / 41 / 37 / 34
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 288 X 800 X 206 310 X 1065 X 224
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 351 X 894 X 280 386 X 1136 X 285
UNIT WEIGHT kg 9 6.3
CONDENSATE DRAIN SIZE mm 16 19.1
FAN
TYPE CROSS FLOW FAN
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP44 IP20
INSULATION GRADE CLASS E
RATED INPUT POWER W 34 42 37 63
RATED RUNNING CURRENT A 0.19 0.21 0.32 0.56
MOTOR OUTPUT W 18 40
POLES 48
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.18 0.29
ROW 2
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 2
CASING COLOUR WHITE
OUTDOOR UNIT
AIR FLOW l/s / CFM 521 / 1100 473 / 1000 869 / 1842
SOUND PRESSURE LEVEL dBA 48 49 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 550 X 765 X 285 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 610 X 895 X 360 793 X 990 X 415
UNIT WEIGHT kg 31 33 49
PIPE CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.4 6.4 6.4 6.4
GAS mm 9.5 12.7 12.7 15.9
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP24 IP34
INSULATION GRADE CLASS E CLASS F
RATED INPUT POWER W 66 67 120
RATED RUNNING CURRENT A 0.31 0.52
MOTOR OUTPUT W 26 66
POLES 6
COMPRESSOR
TYPE ROTARY ROTARY SWING
OIL TYPE RB68A or FREOL ALPHA68M ETHER
OIL AMOUNT cm
3
320 N/A
RATED INPUT POWER (COOLING) W 660 941 1296 1690
RATED INPUT POWER (HEATING) W 728 941 1334 1518
RATED RUNNING CURRENT
(COOLING)
A 3.6 4.48 5.66 7.25
RATED RUNNING CURRENT
(HEATING)
A 3.5 4.38 5.84 6.52
LOCKED ROTOR AMP. A -
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (CORR.)
FACE AREA m
2
0.42 0.4 0.62
ROW 12
CASING COLOUR LIGHT GREY
DRAWING NUMBER 000452103D10 000452103D15 000452103E20 000452103E25
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
