A5LCY_(i) Engineering & Physical Data
MODEL: A5CKY-CR
MODEL
INDOOR UNIT A5CKY10CR A5CKY15CR A5CKY20CR
OUTDOOR UNIT A5LCY10DR A5LCY15DR A5LCY20CR
NOMINAL COOLING CAPACITY
Btu/h 9792 (4026 - 11942) 12385 (5254 - 13306) 18118 (6346 - 20643)
W 2870 (1180 - 3500) 3630 (1540 - 3900) 5310 (1860 - 6050)
NOMINAL HEATING CAPACITY
Btu/h 10884 (3753 - 13989) 13239 (3650 - 15865) 19039 (5050 - 19517)
W 3190 (1100 - 4100) 3880 (1070 - 4650) 5580 (1480 - 5720)
NOMINAL TOTAL INPUT POWER (COOLING) W 780 1006 1654
NOMINAL TOTAL INPUT POWER (HEATING) W 792 1024 1701
NOMINAL RUNNING CURRENT (COOLING) A 4.26 4.70 7.26
NOMINAL RUNNING CURRENT (HEATING) A 4.01 4.90 7.78
EER W/W 3.68 3.61 3.21
COP W/W 4.03 3.79 3.28
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR EXV
REFRIGERANT CHARGE kg 0.75 1.10 1.45
POWER SOURCE V/Ph/Hz 220~240 /1/ 50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 193 / 410 212 / 450
MEDIUM l/s / CFM 184 / 390 203 / 430
LOW l/s / CFM 170 / 360 193 / 410
SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 43 / 42 44 / 42 / 41 47 / 46 / 44
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 250 X 570 X 570
WITH PANEL HEIGHT X WIDTH X DEPTH mm 295 X 640 X 640
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 317 X 630 X 630
PANEL HEIGHT X WIDTH X DEPTH mm 127 X 700 X 700
UNIT WEIGHT (UNIT + PANEL) kg 22 + 2 23 + 2
CONDENSATE DRAIN SIZE mm 19.1
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 152 176 221
RATED RUNNING CURRENT A 0.67 0.79 0.97
MOTOR OUTPUT W 50 60 100
POLES 6
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.25
ROW 2
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM 521 / 1100 473 / 1000 869 / 1842
SOUND PRESSURE LEVEL dBA 48 49 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 550 X 765 X 285 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 610 X 895 X 360 793 X 990 X 415
UNIT WEIGHT kg 31 33 49
PIPE CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.4 6.4 6.4
GAS mm 9.5 12.7 12.7
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP24 IP34
INSULATION GRADE CLASS E CLASS F
RATED INPUT POWER W 66 67 120
RATED RUNNING CURRENT A 0.31 0.52
MOTOR OUTPUT W 26 66
POLES 6
COMPRESSOR
TYPE ROTARY ROTARY SWING
OIL TYPE RB68A or FREOL ALPHA68M ETHER
OIL AMOUNT cm
3
320 N/A
RATED INPUT POWER (COOLING) W 660 941 1296
RATED INPUT POWER (HEATING) W 728 941 1334
RATED RUNNING CURRENT
(COOLING)
A 3.6 4.48 5.66
RATED RUNNING CURRENT
(HEATING)
A 3.5 4.38 5.84
LOCKED ROTOR AMP. A -
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (CORR.)
FACE AREA m
2
0.42 0.4 0.62
ROW 12
CASING COLOUR LIGHT GREY
DRAWING NUMBER 000452103G10 000452103G15 000452103H20
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
