A5LCY_(i) Engineering & Physical Data
MODEL: A5CCY-CR
MODEL
INDOOR UNIT A5CCY10CR A5CCY15CR A5CCY20CR A5CCY25CR
OUTDOOR UNIT A5LCY10DR A5LCY15DR A5LCY20CR A5LCY25CR
NOMINAL COOLING CAPACITY
Btu/h 8769 (4504 - 11361) 12522 (5050 - 12829) 17742 (6892 - 20472) 20643 (6346 - 20643)
W 2570 (1320 - 3330) 3670 (1480 - 3760) 5200 (2020 - 6000) 6050 (1860 - 6050)
NOMINAL HEATING CAPACITY
Btu/h 9451 (2389 - 12897) 12624 (3719 - 14671) 19687 (5391 - 22895) 21873 (5357 - 22758)
W 2770 (700 - 3780) 3700 (1090 - 4300) 5770 (1580 - 6710) 6400 (1570 - 6670)
NOMINAL TOTAL INPUT POWER (COOLING) W 791 1089 1604 1917
NOMINAL TOTAL INPUT POWER (HEATING) W 812 1066 1694 1775
NOMINAL RUNNING CURRENT (COOLING) A 4.43 4.91 7.34 8.90
NOMINAL RUNNING CURRENT (HEATING) A 4.29 4.80 7.74 8.11
EER W/W 3.25 3.37 3.24 3.21
COP W/W 3.41 3.47 3.41 3.66
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR EXV
REFRIGERANT CHARGE kg 0.75 1.10 1.45 1.50
POWER SOURCE V/Ph/Hz 220~240 /1/ 50
REFRIGERANT TYPE R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED
OPERATION WIRED MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 172 / 365 194 / 410 269 / 570 326 / 690
MEDIUM l/s / CFM 160 / 340 175 / 370 255 / 540 302 / 640
LOW l/s / CFM 137 / 290 118 / 250 213 / 450 245 / 520
EXTERNAL STATIC PRESSURE (H/M/L) Pa 29 / 25 / 19 29 / 20 / 10
SOUND PRESSURE LEVEL (H/M/L) dBA 35 / 32 / 26 37 / 34 / 29 38 / 36 / 34 40 / 39 / 36
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 261 X 905 X 411 261 X 1065 X 411 261 X 1200 X 411
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 376 X 1091 X 541 376 X 1251 X 541 376 X 1386 X 541
UNIT WEIGHT (UNIT + PANEL) kg 9.5 11.3
CONDENSATE DRAIN SIZE mm 19.1
FAN
TYPE SIROCCO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) N/A
INSULATION GRADE CLASS B CLASS E CLASS B
RATED INPUT POWER W 89 100 133 164
RATED RUNNING CURRENT A 0.39 0.42 0.61 0.74
MOTOR OUTPUT W 40 50 80 100
POLES 4
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (HYDROPHILIC FIN)
FACE AREA m
2
0.13 0.16 0.19
ROW 3
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT POWDER PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 521 / 1100 473 / 1000 869 / 1842
SOUND PRESSURE LEVEL dBA 48 49 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 550 X 765 X 285 753 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 610 X 895 X 360 793 X 990 X 415
UNIT WEIGHT kg 31 33 49
PIPE CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.4 6.4 6.4 6.4
GAS mm 9.5 12.7 12.7 15.9
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP24 IP34
INSULATION GRADE CLASS E CLASS F
RATED INPUT POWER W 66 67 120
RATED RUNNING CURRENT A 0.31 0.52
MOTOR OUTPUT W 26 66
POLES 6
COMPRESSOR
TYPE ROTARY ROTARY SWING
OIL TYPE RB68A or FREOL ALPHA68M ETHER
OIL AMOUNT cm
3
320 N/A
RATED INPUT POWER (COOLING) W 660 941 1296 1690
RATED INPUT POWER (HEATING) W 728 941 1334 1518
RATED RUNNING CURRENT
(COOLING)
A 3.6 4.48 5.66 7.25
RATED RUNNING CURRENT
(HEATING)
A 3.5 4.38 5.84 6.52
LOCKED ROTOR AMP. A -
COIL
TUBE
MATERIAL SEAMLESS INNER GROOVE COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM (CORR.)
FACE AREA m
2
0.42 0.4 0.62
ROW 12
CASING COLOUR LIGHT GREY
DRAWING NUMBER 000452113J10 000452113J15 000452113K20 000452113K25
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
