HEATING MODE
R410A Models
(Heatpump)
MODEL : A5WM 20GR / A5LC 20CR (3 PHASE)
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.206 3.550 4.976 3.280 4.711 3.049 4.447 2.818 4.182 2.587 3.864 2.310
16
5.402 3.346 5.156 3.114 4.892 2.902 4.628 2.689 4.365 2.477 4.049 2.222
16
5.402 4.235 5.156 4.003 4.892 3.791 4.628 3.579 4.365 3.366 4.049 3.112
17
5.597 4.031 5.335 3.838 5.073 3.644 4.810 3.450 4.548 3.256 4.233 3.024
18
5.809 3.810 5.541 3.642 5.274 3.474 5.006 3.306 4.739 3.138 4.417 2.936
19
6.025 3.571 5.775 3.345 5.526 3.120 5.276 2.894 4.970 2.873 4.602 2.848
20
6.229 3.353 5.935 3.175 5.640 2.997 5.346 2.819 5.052 2.641 4.699 2.428
18
5.809 4.699 5.541 4.531 5.274 4.363 5.006 4.195 4.739 4.027 4.417 3.825
19
6.025 4.460 5.775 4.235 5.526 4.009 5.276 3.783 4.970 3.762 4.602 3.737
20
6.229 4.243 5.935 4.065 5.640 3.887 5.346 3.709 5.052 3.531 4.699 3.317
21
6.437 4.008 6.121 3.795 5.806 3.581 5.490 3.367 5.174 3.153 4.795 2.897
22
6.646 3.774 6.308 3.525 5.971 3.275 5.634 3.025 5.297 2.776 4.892 2.476
23
6.854 3.540 6.495 3.255 6.136 2.969 5.778 2.684 5.419 2.398 4.988 2.056
24
7.062 3.306 6.682 2.985 6.302 2.663 5.922 2.342 5.541 2.021 5.085 1.635
20
6.229 4.687 5.935 4.509 5.640 4.331 5.346 4.153 5.052 3.975 4.699 3.762
21
6.437 4.453 6.121 4.239 5.806 4.025 5.490 3.812 5.174 3.598 4.795 3.341
22
6.646 4.219 6.308 3.969 5.971 3.720 5.634 3.470 5.297 3.220 4.892 2.921
23
6.854 3.985 6.495 3.699 6.136 3.414 5.778 3.128 5.419 2.843 4.988 2.500
24
7.062 3.750 6.682 3.429 6.302 3.108 5.922 2.787 5.541 2.465 5.085 2.080
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.278 3.278 3.710 3.710 3.854 3.854 5.438 5.438 6.302 6.302 6.735 6.735 7.167 7.167
17 3.192 3.192 3.598 3.598 3.776 3.776 5.432 5.432 6.259 6.259 6.697 6.697 7.135 7.135
19 3.106 3.106 3.485 3.485 3.698 3.698 5.425 5.425 6.215 6.215 6.659 6.659 7.103 7.103
21
3.020 3.020 3.401 3.401 3.620 3.620 5.376 5.376 6.171 6.171 6.621 6.621 7.071 7.071
23
2.934 2.934 3.344 3.344 3.542 3.542 5.285 5.285 6.127 6.127 6.583 6.583 7.039 7.039
25 2.848 2.848 3.287 3.287 3.464 3.464 5.194 5.194 6.083 6.083 6.545 6.545 7.007 7.007
27 2.762 2.762 3.230 3.230 3.386 3.386 5.103 5.103 6.039 6.039 6.507 6.507 6.975 6.975
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
