HEATING MODE
R22 Models
(Heatpump)
MODEL : AWM 10GR / ALC 10CR
COOLING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.169 1.968 2.966 1.780 2.762 1.592 2.558 1.403 2.355 1.215 2.111 0.989
16
3.206 1.800 3.012 1.635 2.817 1.470 2.623 1.306 2.429 1.141 2.195 0.943
16
3.206 2.386 3.012 2.222 2.817 2.057 2.623 1.892 2.429 1.728 2.195 1.530
17
3.243 2.218 3.058 2.077 2.872 1.936 2.687 1.794 2.502 1.653 2.280 1.484
18
3.280 2.049 3.104 1.932 2.928 1.814 2.752 1.697 2.576 1.579 2.364 1.438
19
3.317 1.881 3.150 1.787 2.983 1.693 2.816 1.599 2.649 1.505 2.449 1.392
20
3.353 1.711 3.193 1.635 3.033 1.559 2.873 1.483 2.713 1.407 2.521 1.315
18
3.280 2.636 3.104 2.518 2.928 2.401 2.752 2.283 2.576 2.166 2.364 2.025
19
3.317 2.467 3.150 2.373 2.983 2.279 2.816 2.186 2.649 2.092 2.449 1.979
20
3.353 2.298 3.193 2.222 3.033 2.146 2.873 2.070 2.713 1.993 2.521 1.902
21
3.389 2.128 3.235 2.066 3.080 2.004 2.925 1.942 2.771 1.879 2.585 1.805
22
3.426 1.959 3.276 1.910 3.127 1.862 2.978 1.814 2.828 1.765 2.649 1.707
23
3.462 1.789 3.318 1.754 3.174 1.720 3.030 1.686 2.886 1.651 2.713 1.610
24
3.499 1.619 3.360 1.599 3.221 1.578 3.082 1.558 2.943 1.537 2.776 1.513
20
3.353 2.591 3.193 2.515 3.033 2.439 2.873 2.363 2.713 2.287 2.521 2.195
21
3.389 2.422 3.235 2.359 3.080 2.297 2.925 2.235 2.771 2.173 2.585 2.098
22
3.426 2.252 3.276 2.204 3.127 2.155 2.978 2.107 2.828 2.059 2.649 2.001
23
3.462 2.082 3.318 2.048 3.174 2.013 3.030 1.979 2.886 1.945 2.713 1.903
24
3.499 1.912 3.360 1.892 3.221 1.872 3.082 1.851 2.943 1.831 2.776 1.806
46ID DB°C ID WB°C
20
24
28
30
Outdoor DB°C
20 25 30 35 40
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15 1.274 1.274 1.577 1.577 1.678 1.678 2.789 2.789 3.395 3.395 3.698 3.698 4.001 4.001
17
1.246 1.246 1.546 1.546 1.646 1.646 2.743 2.743 3.302 3.302 3.595 3.595 3.887 3.887
19 1.219 1.219 1.516 1.516 1.615 1.615 2.697 2.697 3.210 3.210 3.492 3.492 3.773 3.773
21
1.191 1.191 1.485 1.485 1.583 1.583 2.652 2.652 3.118 3.118 3.388 3.388 3.659 3.659
23 1.184 1.184 1.460 1.460 1.551 1.551 2.554 2.554 3.025 3.025 3.285 3.285 3.546 3.546
25
1.178 1.178 1.434 1.434 1.520 1.520 2.457 2.457 2.933 2.933 3.182 3.182 3.432 3.432
27 1.172 1.172 1.409 1.409 1.488 1.488 2.359 2.359 2.841 2.841 3.079 3.079 3.318 3.318
ID DB°C -9 -6
FROST REGION
-5 6 12 15
Outdoor WB°C
18
