Acson ADB-B Series User Manual

TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
16
Model
Indoor
ADB125B
ADB150B1
ADB200B2
Outdoor
AMC125B
AMC150C
AMC100B x 2
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
1
1
1
B) Outdoor
mm²
4
6
4
C) Total
mm²
4
10
10
Number of Conductors
A) Indoor
3
3
5
B) Outdoor
5
5
5
Interconnection cable size*
mm²
1
1
1
Number of Conductors
4
4
1 x 2
Recommended fuse/circuit breaker rating*
A) Indoor
A
6
6
10
B) Outdoor
A
40
50
32
C) Total
A
40
63
63
Model
Indoor
ADB200B2
ADB250B2
ADB300B2
Outdoor
AMC100C x 2
AMC125B x 2
AMC150C x 2
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
1
1
1
B) Outdoor
mm²
4
4
6
C) Total
mm²
10
16
25
Number of Conductors
A) Indoor
5
5
5
B) Outdoor
5
5
5
Interconnection cable size*
mm²
1
1
1
Number of Conductors
1 x 2
1 x 2
1 x 2
Recommended fuse/circuit breaker rating*
A) Indoor
A
10
16
16
B) Outdoor
A
32
40
50
C) Total
A
63
80
125
Model
Indoor
ADB300B3
ADB300B3
Outdoor
AMC100B x 3
AMC100C x 3
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
1
1
B) Outdoor
mm²
4
4
C) Total
mm²
25
25
Number of Conductors
A) Indoor
5
5
B) Outdoor
5
5
Interconnection cable size*
mm²
1
1
Number of Conductors
1 X 3
1 x 3
Recommended fuse/circuit breaker rating*
A) Indoor
A
16
16
B) Outdoor
A
32
32
C) Total
A
100
100
