Acson ADB-B Series User Manual

TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
17
Model
Indoor
ADB350B3
ADB400B4
Outdoor
AMC100B
AMC125B x 2
AMC100B x 4
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
1.5
1
B) Outdoor
mm²
4
4
C) Total
mm²
25
35
Number of Conductors
A) Indoor
5
5
5
B) Outdoor
5
5
5
Interconnection cable size*
mm²
1
1
1
Number of Conductors
1
1 X 2
1 X 4
Recommended fuse/circuit breaker rating*
A) Indoor
A
20
20
B) Outdoor
A
32
32
C) Total
A
125
150
Model
Indoor
ADB400B4
ADB450B3
ADB500B4
Outdoor
AMC100C x 4
AMC150C x 3
AMC125B x 4
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
1
1.5
2.5
B) Outdoor
mm²
4
6
4
C) Total
mm²
35
50
50
Number of Conductors
A) Indoor
5
5
5
B) Outdoor
5
5
5
Interconnection cable size*
mm²
1
1
1
Number of Conductors
1 X 4
1 X 3
1 X 4
Recommended fuse/circuit breaker rating*
A) Indoor
A
20
25
32
B) Outdoor
A
32
50
40
C) Total
A
150
175
175
Model
Indoor
ADB600B4
ADB750B5
Outdoor
AMC150C x 4
AMC150C x 5
Voltage Range**
Indoor
380 - 415V /3Ph /50Hz + N +
Outdoor
380 - 415V /3Ph /50Hz + N +
Power supply cable size*
A) Indoor
mm²
4
6
B) Outdoor
mm²
6
6
C) Total
mm²
70
120
Number of Conductors
A) Indoor
5
5
B) Outdoor
5
5
Interconnection cable size*
mm²
1
1
Number of Conductors
1 X 4
1 X 5
Recommended fuse/circuit breaker rating*
A) Indoor
A
32
50
B) Outdoor
A
50
50
C) Total
A
200
300
