TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
79
MODEL
INDOOR UNIT
ADB125B
ADB150B1
OUTDOOR UNIT
AMC125B (PFC)
AMC150C (PFC)
NOMINAL COOLING CAPACITY
Btu/h
125,000
150,000
W
36,640
43,960
NOMINAL TOTAL INPUT POWER (COOLING)
W
11,850
15,760
NOMINAL RUNNING CURRENT (COOLING)
A
20.8
30.8
EER
W/W
3.09
2.79
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
INDOOR TXV
REFRIGERANT CHARGE
kg
5.1
5.7
POWER SOURCE
V/Ph/Hz
380 ~ 415/3/50
380 ~ 415/3/50
REFRIGERANT TYPE
R22
R22
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
DUCTED
OPERATION
WIRED CONTROL
WIRED CONTROL
AIR FLOW
CFM
4200
4600
EXTERNAL STATIC PRESSURE (WITHOUT FILTER)
Pa
230
230
SOUND PRESSURE LEVEL
dBA
58
60
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
885 X 1540 X 850
885 X 1540 X 850
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1154 X 1787 X 1188
1154 X 1787 X 1188
UNIT WEIGHT [WITH PANEL]
kg
173
180
CONDENSATE DRAIN SIZE
mm
34
34
FAN
TYPE
CENTRIFUGAL
CENTRIFUGAL
DRIVE
BELT DRIVEN
BELT DRIVEN
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP55
IP55
INSULATION GRADE
F
F
RATED INPUT POWER
W
1620
1910
RATED RUNNING CURRENT
A
3.3
4.03
MOTOR OUTPUT
W
1500
2200
POLES
4
4
COIL
TUBE
MATERIAL
COPPER
COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.01
1.01
ROW
2
3
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET FILTER
WASAHABLE SARANET FILTER
QUANTITY
pc
3
3
CASING
COLOUR
IVORY WHITE
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
6400
8500
SOUND PRESSURE LEVEL
dBA
64
67
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
946 X 939 X 1116
1041 X 939 X 1116
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1132 X 1112 X 1312
1227 X 1112 X 1312
UNIT WEIGHT
kg
160
179
PIPE
CONNECTION
TYPE
BRAZED
BRAZED
SIZE
LIQUID
mm
15.88
15.88
GAS
mm
34.92
34.92
FAN
TYPE
PROPELLER
PROPELLER
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP44
IP54
INSULATION GRADE
F
F
RATED INPUT POWER
W
655
984
RATED RUNNING CURRENT
A
1.21
2.77
MOTOR OUTPUT
W
580
750
POLES
6
8
COMPRESSOR
TYPE
SCROLL
SCROLL
OIL TYPE
MINERAL OIL
MINERAL OIL
OIL AMOUNT
cm
3
3130
3250
RATED INPUT POWER
W
9575
12866
RATED RUNNING CURRENT
A
16.3
24
LOCKED ROTOR AMP.
A
118
174
COIL
TUBE
MATERIAL
ALUMINIUM
ALUMINIUM
DIAMETER
mm
N/A
N/A
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.37
1.73
ROW
1 X 2
1 X 2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB / 19°C WB
OUTDOOR: 35°C DB / 24°C WB
