TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
80
MODEL
INDOOR UNIT
ADB200B2
ADB250B2
OUTDOOR UNIT
AMC100B X 2 (PFC)
AMC125B X 2 (PFC)
NOMINAL COOLING CAPACITY
Btu/h
200,000
250,000
W
58,620
73,270
NOMINAL TOTAL INPUT POWER (COOLING)
W
20,250
24,430
NOMINAL RUNNING CURRENT (COOLING)
A
35.9
42.7
EER
W/W
2.89
3
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
INDOOR TXV
REFRIGERANT CHARGE
kg
5.0 (x2)
5.1 (x2)
POWER SOURCE
V/Ph/Hz
380 ~ 415/3/50
380 ~ 415/3/50
REFRIGERANT TYPE
R22
R22
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
DUCTED
OPERATION
WIRED CONTROL
WIRED CONTROL
AIR FLOW
CFM
6400
8000
EXTERNAL STATIC PRESSURE (WITHOUT FILTER)
Pa
265
280
SOUND PRESSURE LEVEL
dBA
61
63
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
885 X 1794 X 850
1231 X1766 X 1069
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1154 X 2052 X 1188
1506 X 2034 X 1412
UNIT WEIGHT [WITH PANEL]
kg
220
343
CONDENSATE DRAIN SIZE
mm
34
34
FAN
TYPE
CENTRIFUGAL
CENTRIFUGAL
DRIVE
BELT DRIVEN
BELT DRIVEN
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP55
IP55
INSULATION GRADE
F
F
RATED INPUT POWER
W
2930
3970
RATED RUNNING CURRENT
A
5.45
7.66
MOTOR OUTPUT
W
3000
4000
POLES
4
4
COIL
TUBE
MATERIAL
COPPER
COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.20
1.49
ROW
4
4
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET FILTER
WASAHABLE SARANET FILTER
QUANTITY
pc
3
6
CASING
COLOUR
IVORY WHITE
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
6400
6400
SOUND PRESSURE LEVEL
dBA
68
64
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
946 X 939 X 1116
946 X 939 X 1116
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1132 X 1112 X 1312
1132 X 1112 X 1312
UNIT WEIGHT
kg
160
160
PIPE
CONNECTION
TYPE
BRAZED
BRAZED
SIZE
LIQUID
mm
15.88
15.88
GAS
mm
28.58
34.92
FAN
TYPE
PROPELLER
PROPELLER
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP44
IP44
INSULATION GRADE
F
F
RATED INPUT POWER
W
590
655
RATED RUNNING CURRENT
A
1.45
1.21
MOTOR OUTPUT
W
580
580
POLES
6
6
COMPRESSOR
TYPE
SCROLL
SCROLL
OIL TYPE
MINERAL OIL
MINERAL OIL
OIL AMOUNT
cm
3
3130
3130
RATED INPUT POWER
W
8005
9575
RATED RUNNING CURRENT
A
14
16.3
LOCKED ROTOR AMP.
A
118
118
COIL
TUBE
MATERIAL
ALUMINIUM
ALUMINIUM
DIAMETER
mm
N/A
N/A
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.37
1.37
ROW
1 X 2
1 X 2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB / 19°C WB
OUTDOOR: 35°C DB / 24°C WB
