Acson RCM 20 D User Manual

HEATPUMP MODEL – R407C
MODEL : RCM 20DR / A4LC 20BR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 4.595 4.416 4.256 4.097 3.708 3.439 3.309 2.369 3.218
SC 4.273 4.162 4.063 3.964 3.588 3.327 3.201 2.291 3.114
15 TC 5.040 4.786 4.559 4.333 3.921 3.637 3.499 2.505 3.403
SC 4.169 4.053 3.949 3.845 3.480 3.228 3.105 2.222 3.020
18 TC 6.254 5.795 5.385 4.975 4.503 4.177 4.019 2.877 3.908
SC 3.886 3.755 3.638 3.521 3.186 2.955 2.844 2.036 2.765
19.4 TC 6.820 6.266 5.771 5.275 4.775 4.428 4.261 3.050 4.144
SC 3.754 3.616 3.493 3.369 3.049 2.828 2.721 1.948 2.647
20 TC 7.063 6.484 5.967 5.450 4.933 4.575 4.402 3.151 4.281
SC 3.698 3.549 3.416 3.283 2.971 2.756 2.652 1.898 2.579
22 TC 7.873 7.212 6.622 6.031 5.459 5.063 4.871 3.487 4.738
SC 3.509 3.325 3.160 2.996 2.712 2.515 2.420 1.732 2.353
24 TC 8.682 7.939 7.276 6.613 5.985 5.551 5.341 3.823 5.195
SC 3.321 3.101 2.905 2.709 2.452 2.274 2.188 1.566 2.128
HIGH AMBIENT
MODEL : RCM 25DR / A4LC 25BR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 4.982 4.831 4.696 4.562 4.421 4.197 4.089 3.099 4.015
SC 3.945 4.012 4.073 4.133 4.006 3.802 3.704 2.807 3.637
15 TC 5.365 5.180 5.016 4.851 4.702 4.463 4.348 3.296 4.269
SC 3.893 3.949 3.998 4.047 3.922 3.723 3.627 2.749 3.562
18 TC 6.409 6.133 5.886 5.640 5.466 5.189 5.055 3.831 4.963
SC 3.754 3.775 3.794 3.813 3.695 3.508 3.417 2.590 3.355
19.4 TC 6.896 6.577 6.293 6.008 5.823 5.527 5.385 4.082 5.287
SC 3.689 3.694 3.699 3.703 3.589 3.407 3.319 2.516 3.259
20 TC 7.105 6.755 6.444 6.132 5.943 5.641 5.496 4.166 5.396
SC 3.661 3.639 3.619 3.599 3.488 3.311 3.226 2.445 3.167
22 TC 7.801 7.350 6.947 6.544 6.342 6.020 5.865 4.445 5.759
SC 3.568 3.454 3.353 3.252 3.152 2.992 2.915 2.209 2.862
24 TC 8.497 7.944 7.450 6.956 6.742 6.399 6.235 4.726 6.122
SC 3.475 3.270 3.088 2.905 2.816 2.673 2.604 1.974 2.557
HIGH AMBIENT
MODEL : RCM 30DR / A4LC 30CR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 7.295 7.030 6.793 6.556 6.242 5.914 5.658 4.605 5.373
SC 7.094 6.871 6.672 6.472 6.162 5.838 5.586 4.546 5.305
15 TC 7.945 7.586 7.265 6.945 6.612 6.264 5.994 4.878 5.692
SC 6.911 6.674 6.463 6.252 5.952 5.639 5.396 4.392 5.124
18 TC 9.717 9.103 8.554 8.005 7.621 7.220 6.908 5.622 6.561
SC 6.412 6.139 5.895 5.651 5.380 5.097 4.877 3.969 4.631
19.4 TC 10.545 9.810 9.155 8.499 8.092 7.667 7.335 5.970 6.966
SC 6.180 5.889 5.630 5.370 5.113 4.844 4.635 3.772 4.401
20 TC 10.899 10.124 9.433 8.741 8.322 7.885 7.544 6.140 7.164
SC 6.080 5.778 5.509 5.239 4.988 4.726 4.522 3.680 4.294
22 TC 12.081 11.171 10.360 9.548 9.090 8.612 8.240 6.706 7.825
SC 5.748 5.409 5.107 4.804 4.574 4.333 4.146 3.374 3.937
24 TC 13.262 12.218 11.286 10.354 9.858 9.340 8.936 7.273 8.486
SC 5.416 5.040 4.704 4.369 4.159 3.940 3.770 3.068 3.580
HIGH AMBIENT
