HEATPUMP MODEL – R407C
MODEL : RCM 40DR / A4LC 40CR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 9.504 9.212 8.951 8.690 7.958 7.223 6.949 5.361 6.847
SC 9.408 9.136 8.893 8.650 7.921 7.190 6.917 5.337 6.815
15 TC 10.616 10.122 9.680 9.238 8.459 7.679 7.387 5.699 7.279
SC 9.202 8.908 8.645 8.382 7.676 6.967 6.703 5.171 6.605
18 TC 13.650 12.603 11.668 10.733 9.828 8.921 8.582 6.621 8.456
SC 8.639 8.285 7.969 7.653 7.008 6.361 6.119 4.721 6.030
19.4 TC 15.065 13.760 12.595 11.430 10.467 9.501 9.140 7.052 9.006
SC 8.377 7.995 7.653 7.312 6.696 6.078 5.847 4.511 5.761
20 TC 15.672 14.303 13.080 11.857 10.858 9.856 9.481 7.315 9.342
SC 8.264 7.861 7.502 7.142 6.540 5.936 5.711 4.406 5.627
22 TC 17.694 16.110 14.695 13.280 12.161 11.038 10.619 8.193 10.464
SC 7.889 7.417 6.996 6.574 6.020 5.464 5.257 4.056 5.180
24 TC 19.717 17.917 16.310 14.703 13.464 12.221 11.757 9.071 11.585
SC 7.514 6.973 6.490 6.006 5.500 4.993 4.803 3.706 4.733
HIGH AMBIENT
MODEL : RCM 50DR / A4LC 50CR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 11.782 11.404 11.067 10.730 10.110 9.541 9.209 9.058 8.915
SC 11.375 11.083 10.822 10.562 9.951 9.392 9.065 8.916 8.776
15 TC 13.270 12.598 11.998 11.398 10.739 10.135 9.782 9.622 9.470
SC 11.098 10.742 10.425 10.108 9.523 8.988 8.675 8.533 8.398
18 TC 17.328 15.853 14.536 13.218 12.454 11.754 11.345 11.158 10.983
SC 10.341 9.813 9.341 8.869 8.357 7.887 7.612 7.487 7.369
19.4 TC 19.222 17.372 15.720 14.068 13.255 12.509 12.074 11.876 11.689
SC 9.988 9.379 8.835 8.291 7.812 7.373 7.116 6.999 6.889
20 TC 20.034 18.104 16.380 14.657 13.810 13.033 12.580 12.373 12.178
SC 9.837 9.219 8.667 8.115 7.646 7.216 6.965 6.850 6.742
22 TC 22.739 20.542 18.581 16.620 15.659 14.779 14.265 14.030 13.809
SC 9.332 8.684 8.105 7.526 7.091 6.692 6.460 6.353 6.253
24 TC 25.445 22.981 20.782 18.583 17.509 16.524 15.949 15.687 15.440
SC 8.828 8.149 7.544 6.938 6.537 6.169 5.955 5.857 5.764
HIGH AMBIENT
MODEL : RCM 61/62CR / A4LC 61CR (COOLING MODE)
Indoor
DB
Indoor
WB Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46
26.7 13.9 TC 14.344 13.605 12.946 12.286 11.627 10.836
SC 14.344 13.605 12.946 12.286 11.627 10.836
15 TC 15.301 14.432 13.656 12.881 12.106 11.176
SC 13.735 13.049 12.436 11.822 11.209 10.473
18 TC 17.909 16.686 15.596 14.504 13.412 12.103
SC 12.077 11.531 11.044 10.558 10.071 9.487
19.4 TC 19.127 17.739 16.500 15.261 14.023 12.536
SC 11.303 10.823 10.395 9.967 9.540 9.026
20 TC 19.649 18.217 16.938 15.659 14.381 12.845
SC 10.971 10.498 10.077 9.656 9.233 8.728
22 TC 21.387 19.807 18.395 16.983 15.572 13.878
SC 9.865 9.415 9.015 8.614 8.214 7.733
24 TC 23.127 21.397 19.852 18.308 16.763 14.910
SC 8.759 8.333 7.954 7.574 7.194 6.738
Indoor RCM20DR RCM25DR RCM30DR RCM40DR RCM50DR RCM61/62CR
Outdoor A4LC20BR A4LC25BR A4LC30CR A4LC40CR A4LC50CR A4LC61CR
Bypass Factor 0.51 0.60 0.36 0.42 0.31 0.29
34
