ACTpro 120 PSU Operating and Installation Manual
Introduction
The ACTpro 120 is a single door station with an integrated 12 V DC 2A power supply. It
expands any of the existing ACTpro controllers (ACTpro 4000, 4200, 3000, 3200, 2000,
1500) by one door.
The power supply is capable of delivering the full rated 2A current to the load and has an
additional 0.5A for charging the battery.
ACTpro 120 Features and Specification:
Relay contact rating
Main relay 5A / 50 Vac, AUX relay 1A / 50 Vac
Indoor use only
Compatible with all pro
controllers
ACTpro 4200, 4000, 3200, 3000, 2000, 1500
Technical Details:
Supports Clock&Data or Wiegand readers
Multiple entry & exit readers
Reader short circuit protection
Request to exit
Door Monitoring
Tamper and mains present monitoring
Status LED's
Reader current limiting / short circuit protection
Anti passback
Interlocking
Features:
Main relay for door control / AUX relay for alarm monitoring
Supports all ACTpro readers (RFID 125KHz, MIFARE Classic, DESFire EV1)
Break Glass monitoring (ACTpro 4000 and 1500 controllers only)
Voltage Monitoring (ACTpro 4000 and 1500 controllers only)
