ACTpro 120 PSU Operating and Installation Manual
Input Voltage 220-240 V AC
Input Fuse 625mA 250V anti-surge fuse
Output Voltage 13.65V (+/- 2%)
Electronic Output fuse Yes
Battery Current
≈ 0.5A for a battery discharged to ≈ 10V
Battery Protections Deep discharge/Over charge/Reverse polarity
Operating Tempature
-10 to +50 degrees C
Dimensions (H/W/D) 255mm/233mm/86mm
Electrical Specification:
PSU Output Voltage:
12V DC The power supply provides two 12V outputs. One pre-wired to power
the ACTpro 120 door station.
The full load current of 2A is shared between the two outputs.
However the total current from both outputs must not exceed 2A.
Monitoring:
Mains present The PSU MAINS PRESENT output is pre-wired to the MAINS
PRESENT input of the ACTpro 120 door station.
Output Voltage The PSU output voltage level is reported to the ACT PC software and
via the web browser of the ACTpro 1520 and 1500 controller.
Tamper The enclosure lid is tamper monitored.
Note: All faults including Mains Present and Tamper are reported on the
ACT Software and via the web browser on the ACTpro 1520 and
1500 controller.
