ACTsmart2 Operating and Installation Manual Rev. 1.3
13
Change Programming Code:
Step Keypad Entry Operation
1 23 Change Programming code - (default 9999)
2 0001-9999 New 4 - 6 digit programming code
Change Number of PIN Digits:
Step Keypad Entry Operation
1 24 Change Number of PIN digits - (default 4)
2 4-6 Select number of PIN digits in range 4 to 6. When set, the codes require
leading zeros Eg. Code 9999 becomes 009999 for 6 digits.
Limit Number of Users:
This function is useful if the end-user wants to limit the number of user codes and cards permitted to use
the ACTsmart2. This can only be performed when the tamper is open (by removing the main unit from
the mounting plate or the surface mount collar).
Step Keypad Entry Operation
1 10 Add Card Batch
2 Present Card First Card in Batch (lowest number card)
3 Present Card Last Card in Batch (highest number card)
4 0 Enable toggle mode (make sure Option 33 is set)
5 1-8, (optional)* Select each door this batch is valid for
6 Press
✔
End
Adding a Card Batch with Toggle mode:
Step Keypad Entry Operation
1 12 Add PINs (Make sure Option 40 is set on units with keypad)
2 0001-9999 4-6 digit PIN code
30 Enable toggle mode (make sure Option 33 is set)
4 1-8, (optional)* Select each door this PIN is valid for
5 Press
✔
End
Adding a PIN Code with Toggle mode:
Step Keypad Entry Operation
1 26 Limit the number of users allowed to use ACTsmart2 - (default 1000)
2 0001-1000 Maximum number allowed (leading zeroes required)
3 Press
✔
End Setting User Limit
User Toggle:
This function will toggle the door open or closed when a vaild card or PIN is presented. Remember the
Toggle option must be set on the ACTsmart2 (Option 33). To program a card or PIN with the toggle
option, program as normal, but press 0 before the
✔
key. See the two examples below:
