Page #7 background imageLoading...
Page #7 background image
System Requirements Installing the System
System Requirements
Physical Characteristics
ML600 physical characteristics are described in the following table.
Table 1: ML600 chassis physical characteristics
Physical character Measurement
Height 1.6” (40 mm); 1 U when mounted in rack mount sleeve
Width 8.4” (213 mm); 2 units can be mounted side by side in 19” rack
Depth 10” (254 mm) (measured without cables installed)
Weight 3.75 lb (1.7 Kg)
Electrical Requirements
The ML600 requires an external DC power source of -48/-60 VDC nominal (maximum range
-40 VDC to -72 VDC), rated at 24 Watts maximum. For ordering AC supply, see “Appendix
B, Parts List” in the ML600 User Manual.
Clearance and Ventilation Requirements
For problem-free operation, the equipment rack should be located in an area with sufficient
clearance for cabling and adequate ventilation. The intake and exhaust on front and rear of the
system must remain unobstructed. Leave approximately 1 inch clear on both sides.
ML600 Release 5.0a Quick Installation Guide 3
