ENGLISH
CONNECTING TO A VIDEO SCREEN
6.1. DOCK M_VIDEO OR DOCK M_USB2 CONNECTION
• Connect the video cable (preferably Y/C «S-video») between the connection box and the monitor video input.
• Connect the connecting cable between the connection box and the handpiece.
• If you prefer using a footswitch rather than SoproTouch to freeze the image, you just have to connect
the footswitch (optional) to the connection box. With this configuration, SoproTouch is inhibited.
• Connect the power supply to the outlet and to the connection box (the green indicator light should be on).
• Only use the power supply provided with the connection box.
6.2. DOCK MU_USB2 OR DOCK MU_VIDEO CONNECTION
• Please refer to the integration manual of DOCK MU_USB2 / DOCK MU_VIDEO for its connections.
• Connect the connecting cable to the handpiece.
• Connect the video cable (preferably Y/C «S-video») between the connection box and the monitor video input.
6.3. SOPROTOUCH IMAGE FREEZING OPERATION
• When powering on, the camera automatically selects the one-image mode.
• To switch to four-image mode, press for more than three seconds (until a black flash appears on the screen)
SoproTouch (or if you have chosen to use a footswitch, press it for more than three seconds).
• Perform the same handling to switch back to one-image mode.
• In one-image mode, you just have to slightly touch SoproTouch (or to briefly press the footswitch once)
as soon as the desired image appears on the monitor. The image is automatically stored in the camera and
displayed on the screen. If you want to return to direct mode, you just have to slightly touch the SoproTouch
(or press the footswitch) once more.
• Another little gentle touch of the SoproTouch (or press of the footswitch) will freeze another image by
deleting the previous one.
• In four-image mode, the image is stored in one of the quarters of the screen when you slightly touch
SoproTouch (or press the footswitch) and remains displayed on the screen. Another little light touch on
SoproTouch (or press of the footswitch) will return the image to direct mode. A third little light touch
(or press) will store a second image in another quarter of the screen and so on until obtaining the four images.
6
Sopro 617 • User manual
