ACTi E13 - Product Specification

www.acti.com
E13 Hardware User’s Manual
10
Product Specification
E13
• Device
Device Type Cube Camera
Image Sensor Progressive Scan CMOS
Day / Night No
Minimum Illumination Color: 0.1 lux at F2.0 (30 IRE, 2400 °K)
Mechanical IR Cut Filter No
IR Sensitivity Range No
Electronic Shutter 1/5 - 1/2,000 sec (Manual / Auto mode)
• Lens
Focal Length / Aperture Fixed focal, f2.8 mm / F2.0
Iris Fixed iris
Focus Manual focus
Mount Type CS Mount (interchangeable lens)
Horizontal Viewing Angle 81.6°
• Video
Compression H.264 HP, MJPEG
Maximum Frame Rate
vs. Resolution
15fps at 2592 x 1944; 15fps at 2048 x 1536;
30 fps at 1920 x 1080 (Full HD 1080p); 30 fps at 1280 x 720 (HD 720p); 30 fps at 640 x 480 (VGA)
Multi-Streaming Simultaneous dual streams based on two configurations
Bit Rate 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode Constant, Variable
Image Enhancement
Basic WDR; White balance: automatic, hold, and manual; Brightness;
Contrast; Automatic gain control; Digital noise reduction; Flickerless
Privacy Mask 4 configurable regions
Text Overlay User defined text on video
Image Orientation Image flip and mirror
• Audio
Compression 8kHz, Mono, PCM,16 bit encoding; G.711
Audio-In Built-in Microphone
Audio-Out 3.5mm Phone Jack
• Network
Protocol & Service
TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP,
UPnP, SNMP, Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security IP address filtering; HTTPS encryption; Password protected user levels; IEEE 802.1X network access control
• Alarm
Alarm Trigger Video motion detection (3 regions)
Alarm Response
Notify control center; Change camera settings; Command other devices;
E-mail notification with snapshots; Upload video, snapshot to FTP server
• General
Power Source / Consumption PoE Class 2 (IEEE802.3af) / 3.67 W
Weight 205 g (0.45 lb)
Dimensions (Φ x H) 96mm x 96mm x 45.07mm (3.8" x 3.8" x 1.8")
Bundled Accessories Bracket
Mount Type Wall, Ceiling
Operating Temperature -10 °C ~ 45 °C (14 °F ~ 113 °F)
Operating Humidity 10% ~ 85% RH
Approvals CE, FCC
• Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available; ONVIF compliant
Firmware Access Browser Microsoft Internet Explorer 6.0 or newer
