Installation Guide
10
Step 2: Prepare the Accessories
1. Prepare the Cable Gland accessories. Detach the parts as follows:
NOTE: The cable gland comes in two sets, one for the Ethernet cable of the camera and the
other for the network.
2. Insert the clamping nut through the Ethernet cable of the camera.
3. Insert the rubber seal.
Main Body
Rubber Seal
Clamping Nut
