Encoder Hardware Manual
9
Item
Description
8
Ethernet Port
Connects to the network using a standard
Ethernet cable.
9
AC Power Input
Use this connector to connect the bundled
power cord. See Connecting to Power on
page 14 for more information.
10
Power Switch
Press the switch to turn the encoder on or off.
11
Digital Input / Output
Connector
(1~8)
Connects to digital input or output devices,
such as an alarm trigger, panic button, etc.
Digital Input (DI) and Digital Output (DO)
devices are used in applications like motion
detection, event triggering, alarm notifications,
etc. See Connecting the Digital Input/Output
Devices (Optional) on page 16 for more
information.
12
Audio Input Connectors
(1~8)
Connects to audio input devices, such as a
microphone with built-in amplifier, etc. See
Connecting an Audio Input Device on page
21 for more information.
NOTE: The microphone must have a built-in
amplifier. Connecting an ordinary microphone
will dwarf sounds and will result in inaudible
recording.
13
RS-422 / RS-485 Port
(1~2)
Connects to an analog device via RS-485 /
RS-422 serial communication to control
encoder functions like pan-tilt, zoom, etc. See
Connecting a Serial Device (Optional) on
page 23 for more information.
14
Audio Output Connector
Connects to an audio output device, such as a
powered speaker. See
Connecting an Audio Output Device on page
22 for more information.
