ACTi Z81 - Page 11

www.acti.com
Hardware Manual
11
4. Connect the cable and then secure the mounting base.
5. Mount the camera to the base.
Adjust the housing to the position shown in figure figure  then push and turn it to
anywhere but .
6. Adjust the lens viewing direction, and then tighten the screw.
Connect cable and protect
it with waterproof tape
Attach bottom ring to
ceiling with taping screws
(Optional) insert a
micro SD card
1
