Hardware Manual
10
Installation Procedures
Mounting on the Ceiling
1. Locate the positions of the holes; paste the drill template stickers on the surface and then
use a Ø6-6.5mm drill bit to drill 30 mm-depth guide holes according to the positions
marked by drill template.
2. Insert the plastic anchors and drill a hole to lead the cables out of the ceiling.
3. Loosen the fixing screw, then remove the housing.
