SPARK by Action Trampoline Climbing Bar
Step 1
NOTE: Prior to assembly, ensure you have set up on even ground to avoid the ladder the
tipping over.
1. Insert Upper Pole (1) and Lower Pole (2) into Joint 1 (4).
2. Secure with Bolt 2 (10) using a Washer (12) and Screw Nut (11).
3. Tighten with Allen Key (13) and Wrench (14)
4. Repeat for the second support pole.
Assembly Instructions (cont)
Upper Pole
Lower Pole
NOTE: If you have any problems by this stage, please do not try to install the accessory and call 1800 465 070
1
2
4
10
12
11
3
1
1
2
