Action SPARK - Joint

14
SPARK by Action Trampoline Climbing Bar
Step 3
1. Insert Joint 2 (5) between the gap in the frame. Be sure that the metal tab is resting flush on
trampoline frame.
2. Secure pole to the trampoline frame with Bolt 2 (10) into Joint 1 (3).
3. Repeat for the second pole.
Assembly Instructions (cont)
NOTE: Joint 1 (3) should sit flush against the trampoline frame and should line up with Joint
2 (5).
NOTE: If you have any problems by this stage, please do not try to install the accessory and call 1800 465 070
5
10
2
1
Joint 2
