Action SPARK - Pole 2

15
SPARK by Action Trampoline Climbing Bar
Step 4
1. Insert Pole 2 (7) into Joint 1 (4). Ensure the pole is curving inwards.
2. Secure pole into position with Bolt 2 (10), Washer (12) and Screw Nut (11).
3. Tighten with Allen Key (13) and Wrench (14).
4. Repeat for the second pole.
Assembly Instructions (cont)
NOTE: If you have any problems by this stage, please do not try to install the accessory and call 1800 465 070
7
4
10
12
11
3
1
Pole 2
2
