76
Actiontec USB/Ethernet DSL Modem User Manual
77
Appendix B Setting Up Static IP on the Computer
7. The “Local Area Connection Properties window appears. Click General.
8. In the “Components checked are used by this connection list box, double-
click Internet Protocol (TCP/IP).
9. The “Internet Protocol (TCP/IP) Properties window appears.
10. In the General tab, make sure the circle next to “Use the following IP Address
is selected. When active, a black dot appears in the circle. If the circle already
contains a black dot, leave it alone.
11. Enter the following address in the IP Address text box:
192.168.0.2
Enter the periods in the address by pressing the space bar on the keyboard.
