4
Electrics.
A.C. Input 230V~, 50Hz, 1.25 kW Maximum.
DC Output, 24v, 8 Amps.
Duty cycle 10%. maximum: 2min on & 18mins off.
Water pressures.
• Minimum: 1 Bar (Hot & Cold water supplies)
• Maximum: 10 bar (Hot & Cold water supplies)
• Pressures should be equal.
Misc. 1600mm 1700mm
• Water capacity at ave. 300mm depth: 210Ltr 225Ltr
• Product weight (Dry): 110kg 125kg
• Maximum weight (product, User & Water): 470kg 500kg
• Maximum user weight (Seat): 150kg 150kg
• ‘A’ weighted sound emission: <70dB(A) <70dB(A)
Transport and storage.
• Ambient temperature range: 5°C to 70°C
• Relative humidity range: 10 - 80% not condensed at 20°C
• Atmospheric pressure range: 50kPa to 106kPa
Recycling.
• Battery: Recyclable. Not for disposal. Environmental danger
• Packaging: Wood and corrugated cardboard, recyclable
• The product: Electrical components, batteries, steel and plastic parts to
be separated and recycled to local requirements.
Product dimensions.
INSTALLATION
Technical information
Diagram includes optional
Showersafe gantry
