Activeon CX GOLD User Manual

17
11. Quick Menu
Quick menu provides easy access to your
most often used menu.
Quick menu is only available with touch
screen.
1. Swipe up. Then Quick menu screen will
appear.
2. Tap the menu you wish to enter.
12. Recharging battery
LCD will show the low battery icon( ) when the battery is too low and close to the cut o level.
The camera will save the le automatically until it is turned o. You must recharge your battery to restart.
It will take about 3.5 hours for a full charge by USB port.
You can use a Battery Charger (optional accessory) for fast charging.
ON/OFF
SSID-PW
WiFi
WiFi INFO
Function Description
ON/OFF
ON/OFF
ON/OFF(last setting value)
ON/OFF
ON/OFF(last setting value)
ON/OFF(last setting value)
CONTROL BAR
WIFI
UPSIDE DOWN
QUICK REC
SPEAKER
Brightness
MIC
BEEP
Function Description
1. Turn o the camera.
2. Connect the camera to your computer via USB cable.
3. LED will turn on indicating battery is being charged.
4. LED will be turned o when it is fully charged.

Activeon CX GOLD Specifications

General

Product color	Black, Gold
LED indicators	Yes
Waterproof up to	40 m
Protection features	Water resistant, Waterproof
GPS (satellite)	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Aspect ratio	3:2, 4:3, 16:9
Video resolutions	1920 x 1200 pixels
Maximum frame rate	60 fps
Supported video modes	480p, 720p, 960p, 1080p
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Sensor type	CMOS
Total megapixels	16 MP
Display diagonal	2 \
Lens type	Wide-angle
Digital zoom	4 x
Aperture range (F-F)	2.4 - 2.4
USB 2.0 ports quantity	1
Storage media	Memory card
Compatible memory cards	MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Battery capacity	1100 mAh
Battery life (max)	2 h
Cables included	USB
Package width	110 mm
Package height	170 mm
Package weight	370 g

Weight and Dimensions

Depth	23 mm
Width	60 mm
Height	41 mm
Weight	49 g
Weight (including battery)	70 g
