Activeon CX GOLD User Manual

4
How to unlock the Touch operation
●
CX Gold includes special power saving features.
1. Auto Backlight Dimming : When you set [Auto LCD O] , auto backlight dimming will start at mid-
point of your setting time.
2. Quick LCD OFF : Tap and hold the screen for 2-3 seconds. LCD will go o automatically.
* For turning on the LCD again, please press the ( ) button once.
* If lock image appears, please refer to How-to-Unlock-the-Touch-Operation guide.
Power saving features
●
If you want to use touch operation, tap
the screen rst.
And then it will show " Lock image".
Tap and hold the "Lock image" until the
live screen is ready.
3. Start the camera
1. Open the battery cover and insert ACTIVEON CX GOLD Li-ion battery.
2. Insert microSD Card on the microSD Card slot.
(The camera will not record when microSD Card is not inserted.)
3. Press the ( ) button and hold for two seconds. (The camera will turn on and LCD screen will display live screen .)

Activeon CX GOLD Specifications

General

Product color	Black, Gold
LED indicators	Yes
Waterproof up to	40 m
Protection features	Water resistant, Waterproof
GPS (satellite)	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Aspect ratio	3:2, 4:3, 16:9
Video resolutions	1920 x 1200 pixels
Maximum frame rate	60 fps
Supported video modes	480p, 720p, 960p, 1080p
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Sensor type	CMOS
Total megapixels	16 MP
Display diagonal	2 \
Lens type	Wide-angle
Digital zoom	4 x
Aperture range (F-F)	2.4 - 2.4
USB 2.0 ports quantity	1
Storage media	Memory card
Compatible memory cards	MicroSDHC, MicroSDXC
Maximum memory card size	64 GB
Battery capacity	1100 mAh
Battery life (max)	2 h
Cables included	USB
Package width	110 mm
Package height	170 mm
Package weight	370 g

Weight and Dimensions

Depth	23 mm
Width	60 mm
Height	41 mm
Weight	49 g
Weight (including battery)	70 g
