5
1. Remove unit from shipping carton.
2. Remove all protective materials.
3. Check for shipping damage and loose or broken parts.
4. Read owner's manual thoroughly prior to installation.
5. Remove purification plates from the box and install (page 7).
6. Install the internal carbon filter (page 8).
7. Install the rear lint screen (bottom of page 8).
8. Fully insert cord into the power cord receptacle on the back of the unit.
9. Determine placement location for the unit (page 9), plug the unit into a 100 volt, 120
volt, 220 volt, or 240 volt (depending on model) outlet, be sure the power switch is on,
and adjust controls according to the application.
INSTALLATION
Lint
Screen
Ozone Control
Fan Control
Front Grill
Power Switch/
Fuse/Power Cord
Receptacle
Ion Control
Power Indicator Lamp
