4
It is important to be familiar with the parts of the activTek INDUCT 750/2000. If any parts are missing, contact
your sales representative or Distributor.
PRODUCT FEATURES
INSTALLATION HARDWARE (SUPPLIED)
(8) #8 — .75
1/4" Self-tapping screws
Item # US7067
(2) Thumb screws
Item # 36-00213
(2) Thumb nuts
Item # 36-00214
(4) #6 — 32 x 2 inch Threaded bolts
Item # US70680
(4) #6 — 32 Toggle
bolt wall anchors
Item # US70682
RECOMMENDED INSTALLATION TOOLS
3 1/2" Hole Saw
(for wood or metal)
Utility Knife
1/4" Nut
Driver Bit
Drill / Power
Driver
Tin Snips
(for metal ductwork)
Phillips
Screwdriver
Dust Mask
3/8" Drill Bit
(if installing into berglass
ducting with toggle bolts)
1/4
YOU MAY ALSO NEED:
CAUTION
When the unit is installed in a roof mounted HVAC system, the unit must
be protected from elements.
Safety
Switch
UV bulb indicator
Replaceable ActivePure
®
Cell
(includes UV Lamp)
Mounting Plate
