ActronConnect Installation & Commissioning Guide - Website
Doc. No.9590-1001 Version No.3.0 150901C
The instructions herein refer to work involving a Computer CPU •
Chip & Electronic CPU Board, please ensure all Instructions are
followed accurately so as to prevent damage to these fragile & delicate
components.
CODES, REGULATIONS & STANDARDS
The installer and/or contractor assumes responsibility to ensure that
ActronConnect Module installation and commissioning comply with the
relevant council, state / federal codes, regulations and building code
standards. All electrical wiring must be in accordance with current
electrical authority regulations and all wiring connections to be as
per electrical diagram provided with the unit.
SPECIFICATIONS
ActronConnect Module Part No. ACM-1
Wi-Fi Protocol 802.11b/g/n
Operating System Requirement IOS 6.1.3 or later version
Security Protocol Web-128, WPA-PSK, WPA2-PSK
Hardware Voltage 9VDC - 15 VDC
Max. Operating Temperature
60
o
C
IP Rating IP20
Max Cable Length from ACM to
Power Supply Kit
10 metres
Access Point Distance * 15 metres
Wi-Fi Range 70m line of sight
*
The maximum distance that can be established between ACM and mobile device
(i.e. iphone, ipad, laptop) if the mobile device is acting as an access point.
Power Supply Part No. 2020-200K
Output Ratings 12VDC 1.3A 15.6W
Input Ratings 85~264VAC 120~370VDC
- Frequency Range 47~63Hz
- Inrush Current Cold Start 65A / 230VAC
- Effi ciency (Typical) 81%
- AC Current (Typical) 0.35A / 115VAC
0.25A / 230VAC
Working Temperature
-20~+70
o
C
Working Humidity 20-90% RH
non-condensing
Overload Protection Above 105% Rated Power
O/L Protection Type Hiccup mode, auto recovery after
fault condition is removed
Over Voltage Protection 13.8-16.2V
O/V Protection Type Shut-Off o/p voltage, clamping by
zener diode
