Installation and Commisioning Guide
ESP Platinum QUE - Three Phase
01. Inspections
01.01. Product Inspections
Check your air conditioning unit and all items against the invoice upon receiving your shipment. Inspect the unit, components
and accessories for any sign of damage. If there is any damage to the unit, contact ActronAir Customer Care Department
immediately on: 1300 522 722 to obtain a Goods Return Number.
Check the unit nameplate to verify the model, serial number, electrical rated specifications are correct.
01.02. Codes, Regulations and Standards
The installer and/or contractor assumes responsibility to ensure that unit installation complies with the relevant council, state
/ federal codes, regulations and building code standards. All electrical wiring must be in accordance with current electrical
authority regulations and all wiring connections to be as per electrical diagram provided with the unit.
02. General Information
The ActronAir Platinum-Series Split Ducted air conditioning units are designed for applications where superior performance,
high efficiency, reliability, supply air quality and quiet operation are the prime priorities. The units are built with the latest
technology, advanced variable speed driven compressor, EC indoor fans, low-noise outdoor fans and an intelligent electronic
control.
For optimum efficiency, your air conditioning unit will deliver just the right amount of cooling or heating capacity you
demand. Even in extreme conditions, the unit will still supply the required demand at peak performance.
Energy Efficient Refrigeration Circuits
The ActronAir Platinum-Series Split Ducted system is designed with a variable capacity refrigeration circuit that delivers only
the amount of cooling or heating actually required to maintain your desired comfort at the most optimum efficiency.
The refrigeration circuit consists of:
● High efficiency variable capacity scroll compressor with individual compressor drive
● Hydrophillic coated condenser coil designed for optimum performance and efficiency with corrugated fins and
riffled tubing
● Hydrophillic coated evaporator coil designed for optimum performance and efficiency with lanced fins and riffled
tubing
● Electronic expansion valve (EEV), to maintain efficiency at different operating conditions
Evaporator Section
The evaporator section has EC fans which deliver just the right amount of airflow, depending on requirements. The fans
provide superior performance for your comfort at optimum efficiency:
● Highly efficient variable speed EC motor that uses less energy than the traditional AC motor.
● Easy indoor fan commissioning via intelligent controllers.
● Low noise operation.
Condenser Section
Uses two (2) axial fans and an Inverter Compressor, with the following features:
● Efficient Tru-Inverter Compressor and Inverter Drive combination
● Efficient axial fans with direct drive AC motor
● Low noise operation
