Installation & Commissioning Guide - ESP Platinum QUE Split Ducted Units
Doc. No.0525-063 Ver. 1 190131
Installation and Commisioning Guide
ESP Platinum QUE - Three Phase
Electrical Section
The electrical section is composed of a panel for controls and a separate panel enclosure for the variable speed drive.
Durable Design and Construction
ActronAir is an Australian manufacturer with proven high quality air conditioning products. Known for their durability and
reliable performance, these products are designed and built to withstand the extreme weather conditions.
The heavy gauge zinc and galvanized steel cabinet, with powder coated epoxy enamel finish, resists the toughest conditions.
The louvered outdoor coil guard protects the condenser coil from any potential damage brought by hail, stones and other
solid objects that may be projected to the unit.
Blue Hydrophillic coil fins provide protection to your heat exchangers and enhanced heat transfer with increased performance
efficiency.
System Flexibility
The ActronAir Platinum-series of air conditioning units is the first choice for residential, office, schools and other air
conditioning facilities applications, both for new construction or retrofitting projects.
Refrigerant Handling and Accountability
ActronAir strongly urges that all service technicians make every effort possible to reduce the emission of refrigerants to
the atmosphere. Everyone must act in a responsible manner to conserve refrigerants in accordance to the industry code of
practice.
03. Safety Instructions
● Only licensed HVAC technicians* should install and service this air conditioning equipment. Improper service or
alteration by an unqualified technician could result in significant and major damage to the product or property
which may render your warranty null and void. Such unqualified service could also lead to severe physical injury or
death. Follow all safety instructions in this literature and all warning labels that are attached to the equipment.
● Prevailing WH&S regulations must be observed and will take precedence to the safety instructions contained on
this manual. Safe work practices and environment must be the paramount importance in the performance of all the
service procedures.
● Ensure that unit installation complies with relevant council regulations and building code standards.
● All electrical wiring must be in accordance with current electrical authority regulations and all wiring connections to
be as per electrical diagram provided.
● Secure the fans against accidental contact. Beware of pinch point and sharp edges which can cause cutting injury.
● Always wear appropriate PPE, remove any dangling jewellery and protect long hair by wearing a cap.
● Make sure that safety guards and panel covers are always firmly secured and not damaged.
● This appliance is not intended for use by young children or infirm persons unless they have been adequately
supervised by a responsible person to ensure that they can use the appliance safely. Young children should be
supervised to ensure that they do not play with the appliance.
● Installer must incorporate a means of electrical disconnection (isolator) in the sub mains fixed wiring in accordance
with AS/NZS 3000:2018 (also known as Australian Wiring Rules).
● Secure the power cords and control cables that goes in/out the unit. Use the cable ties provided in the control box.
*Qualifications required will be appropriate Electrical, Refrigeration and Refrigerant Handling License & Training
dependent on local State/Territory regulations.
DANGER
Hazardous Voltage - Risk of Electrocution.
TURN-OFF the power from main isolator before proceeding with any service work of the unit. Observe proper LOCK-OUT/TAG-
OUT (LOTO) procedures for electrical appliances in order to prevent accidental switching-on of the power supply.
