ActronAir ESP Platinum QUE - Outdoor Unit Dimensions and Clearances; Unit Dimensions and Weights (CRQ2-16 AT;CRQ3-18 AT)

08
Installation & Commissioning Guide - ESP Platinum QUE Split Ducted Units
Doc. No.0525-063 Ver. 1 190131
Installation and Commisioning Guide
ESP Platinum QUE - Three Phase
06. Outdoor Unit Dimensions / Clearances
06.01. Unit Dimensions and Weights
CRQ2-16AT / CRQ3-18AT
1460 O/A
580
O/A
255
1045
O/A
585
980
517
(MTG C-C DIST)
1000
1118
(MTG C-C DIST)
56
110
115
115
57.5
30
35
25
25
OUTDOOR
AIR INLET
DRAIN
POINT
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
ACCESS
PANEL
OUTDOOR COIL
COMP
ELECT. ACCESS
2 x Ø 25.4mm (1")
GAS PIPE
Ø 19.05mm (3/4")
SWAGED
LIQUID PIPE
Ø 9.52mm (3/8")
SWAGED
340 500
115
RR RF
LR LF
NOTE
• All dimensions are in mm unless specified.
• Do not scale drawing.
• MTG C-C DIST = Mounting Center to Center Distance
UNIT MODEL
NUMBER
UNIT
WEIGHT
(kg)
CORNER WEIGHTS (kg)
RR RF LR LF
CRQ2-16AT 147 33 33 16 65
CRQ3-18AT 158 36 34 20 68
