ActronAir ESP Platinum QUE - Outdoor Unit Dimensions and Clearances (Continued); Unit Dimensions and Weights (CRQ5-21 AT;CRQ5-24 AT)

09
ActronAir is constantly seeking ways to improve the design of its products, therefore specifications are subject to change without notice.
Copyright © 2019 Actron Engineering Pty. Ltd.
Installation and Commisioning Guide
ESP Platinum QUE - Three Phase
CRQ5-21AT / CRQ5-24AT
671
(MTG C-C DIST)
553112
118
59
1105
O/A
670
437
118
58
533
(MTG C-C DIST)
60
1685 O/A
380 565
685
O/A
COMP
OUTDOOR COIL
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
OUTDOOR
AIR INLET
295
125
1025
50
616
(MTG C-C DIST)
210.5
(MTG C-C DIST)
283
36.5
ELECT. ACCESS
2 x Ø 25.4mm (1")
GAS PIPE
Ø 22.2mm (7/8") SWAGED
LIQUID PIPE
Ø 12.7mm (1/2") SWAGED
25 25
DRAIN
POINT
OUTDOOR
AIR OUTLET
OUTDOOR
AIR INLET
RR RF
LR LF
NOTE
• All dimensions are in mm unless specified.
• Do not scale drawing.
UNIT MODE
NUMBER
UNIT
WEIGHT
(kg)
CORNER WEIGHTS (kg)
RR RF LR LF
CRQ5-21AT 203 55 41 16 91
CRQ5-24AT 214 58 42 20 94
