Install the new bulb, and turn it
one-quarter turn clockwise to lock
it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the headlights to test the
new bulb.
Reinstall the coolant reserve tank.
Reinstall the fasteners. Reinstall
the cover and upper part of the air
intake duct securely.
Remove the electrical connector
from the bulb by pushing on the
tab to unlock it, then slide the
connector off the bulb.
Remove the bulb by turning it
approximately one-quarter turn
counterclockwise.
To change a bulb on the left side,
remove the two fasteners by
turning the head of each fastener
with a flat-tip screwdriver, then
remove the cover and upper part
of the air intake duct.
2.
3.
4.
5.
6.
7.
On the passenger’s side
On the driver’s side
Lights
Maintenance
433
COVER
AIR INTAKE DUCT
０８／０２／０６ ２１：３５：３７ ３１ＴＬ１６００ ０４３８
