Acura 2009 TSX User Manual

Lift the anchor cover, then attach
the tether strap hook to the
anchor, making sure the strap is
not twisted.
Tighten the strap according to the
seat maker’s instructions.
A child seat with a tether can be
installed in any seating position in
the back seat, using one of the
anchorage points shown above.
Since a tether can provide additional
security to the lap/shoulder belt
installation, we recommend using a
tether whenever one is required or
available.
After properly securing the child
seat (see page ), route the
tether strap over the seat-back and
through the head restraint legs.
Set the head restraint to its
highest position.
1.
2.
3.
4.
48
Installing a Child Seat
Installing a Child Seat with a
Tether
Using an Anchor
50
TETHER STRAP HOOK
ANCHOR
ANCHOR
ANCHOR
COVER
TETHER ANCHORAGE POINTS
Center PositionOuter Position
TETHER STRAP HOOK
