The spark plugs in your car are a
special platinum-tipped design for
longer life. The spark plugs should
be replaced according to the time
and distance recommendations in
the maintenance schedule.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a flat-tipped
screwdriver. Remove the cover on
the front cylinder bank by pulling
it straight up.
Clean up any dirt and oil that have
collected around the ignition coils.
Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
1.
2.
3.
Replacement
Spark Plugs
Maintenance
256
HHOOLLDDIINNGG CCLLIIPP
IIGGNNIITTIIOONN CCOOIILL
CCOONNNNEECCTTOORR
LLOOCCKK
TTAABB
０２／０１／０９ １４：３３：０９ ３１Ｓ３Ｍ６２０ ０２５９
