582
uuSurround View Camera System
*
uDisplaying an Image From the Surround View Cameras
■
Camera Locations and Images
Ground View
An overhead view created by the
combination of images captured
by four cameras.
Side View
+
Ground
View
Sideview Camera
(Passenger side)
Sideview Camera
(Driver side)
The unique surround view camera lenses make distances appear
differently than they actually are - objects seen on the audio/
information screen may appear closer or further away, and may be
distorted. This becomes more apparent the further away an object is
from your vehicle.
Press the CAMERA
button.
Rearview Camera
Front-view Camera
Audio/
Information
Screen
Front
Wide View
+
Ground
View
Rear Wide View +
Ground View
Rear Normal View +
Ground View
24 ACURA MDX-31TYA6200.book 582 ページ ２０２３年３月２日 木曜日 午後１２時４４分
To Next Page
