uuIf a Tire Goes FlatuChanging a Flat Tire
658
1. Remove the wheel nuts and flat tire.
2. Wipe the mounting surfaces of the wheel
with a clean cloth.
3. Mount the compact spare tire.
4. Screw the wheel nuts until they touch the
lips around the mounting holes, then stop
rotating.
5.
Lower the vehicle and remove the jack.
Tighten the wheel nuts in the order indicated
in the image. Go around tightening the nuts
two to three times in this order.
Wheel nut torque:
94 lbf∙ft (127 N∙m, 13.0 kgf∙m)
6. Set Leveling Control to ON.
2 Leveling Control P. 464
■
Replacing the Flat Tire
1Replacing the Flat Tire
Do not over tighten the wheel nuts by applying extra
torque using your foot or a pipe.
Models with Electronic Air Suspension (EAS)
