ACV PRESTIGE Series User Manual

Central heating Solo AquaSpeed Excellence
24 32 24 32 24 32
Max (intake) pressure kW 24 32 24 32 24 32
Min (intake) pressure kW 5.9 5.9 5.9 5.9 5.9 5.9
Max output 80/60°C kW 23.3 30.8 23.3 30.8 23.3 30.8
Min. output 80/60°C kW 5.8 5.8 5.8 5.8 5.8 5.8
Efficiency (high power) 80/60°C % 97 96 97 96 97 96
Efficiency (low power) 80/60°C % 98 98 98 98 98 98
Efficiency (high power) 45/30°C % 105 104 105 104 105 104
Efficiency (low power) 45/30°C % 107 107 107 107 107 107
Flue gases
C0 emissions CO (high power / min.) mg/kWh 45 / 20 52 / 20 45 / 20 52 / 20 45 / 20 52 / 20
NOx emissions (EN483) mg/kWh 66 66 66 66 66 66
NOx classification 5 5 5 5 5 5
Flue gas temperature — high power 80/60°C °C 92 108 92 108 92 108
Flue gas temperature — high power 45/30°C °C -77-77-77
Mass flow rate of combustion products Kg/h 10.6 14.2 10.6 14.2 10.6 14.2
Flue gas pipe - Max. pressure drop mbar 130 130 130 130 130 130
Concentric flue gas channel maximum length Ø 80 / Ø 125 m 20 20 20 20 20 20
Gas
Category (varies by country) I2E(S)B - I2Er - I2H - I2ELL
Gas pressure — high power (E-Band) mbar 20 20 20 20 20 20
Gas pressure — low power mbar 25 25 25 25 25 25
G20 gas flow rate m
3
/h 1.43 3.4 3.4 3.4 3.4 3.4
G25 gas flow rate m
3
/h 3.9 3.9 3.9 3.9 3.9 3.9
CO2 (high power) G20/25 (with front panel closed) % CO2 9.3 9.3 9.3 9.3 9.3 9.3
CO2 (high power) G20/25 (with front panel open) %CO2 9.0 9.0 9.0 9.0 9.0 9.0
%CO2 (low power) G20/25 (with front panel closed) % CO2 9.2 9.2 9.2 9.2 9.2 9.2
Hydraulic parameters
Max. operating temperature °C 90 90 90 90 90 90
Boiler water capacity l 881414 16 16
Domestic hot water circuit capacity L --0.90.9 54 54
High operating power CC bar 333333
Heat exchanger pressure drop (∆T = 20) mbar 131 210 131 210 131 210
Dimensions
Width mm 500 500 500 500 630 630
Depth mm 400 400 400 400 470 470
Depth (with backing) mm 520 520 520 520 - -
Height mm 900 900 900 900 900 900
Weight Kg ----8686
Electrical connection
Class IP 30 30 30 30 30 30
Supply voltage V/Hz 230~/50 230~/50 230~/50 230~/50 230~/50 230~/50
Electrical power A 0.8 0.8 1.2 1.2 1.2 1.2
6
TECHNICAL DATA
UK
NATURAL GAS MODEL

ACV PRESTIGE Series Specifications

General

Fuel Type	Natural Gas
Installation	Wall-mounted
Heat Exchanger Material	Stainless Steel
Boiler Type	Condensing
Ignition Type	Electronic
Control System	Digital
Heating Capacity	Variable, based on model
Temperature Range	30°C to 85°C
Modulation Range	1:10
