Wiring OLD 0.96" 128x64 OLED
128x64 Version 1.0 OLED
The version 1 128x64 OLED runs at 3.3V and does not have a built in level shifter so you'll need
to use a level shifting chip to use with a 5V microcontroller. The following will assume that is the
case. If you're running a 3.3V microcontroller system, you can skip the level shifter.
We'll assume you want to use this in a
breadboard, take a piece of 0.1" header
10 pins long.
Place the header in a breadboard and
then place the left hand side of the OLED
on top.
And solder the pins
This wiring diagram is only for the older 0.96" OLED that comes with a level shifter
This wiring diagram is only for the older 0.96" OLED that comes with a level shifter
chip. If you did not get a level shifter chip, you have a V2.0 so please check out the
chip. If you did not get a level shifter chip, you have a V2.0 so please check out the
other wiring tutorial!
other wiring tutorial!
