Downloads
You can download our SSD1306 OLED display Arduino library from
github (http://adafru.it/aHq) which comes with example code. The library can print text,
bitmaps, pixels, rectangles, circles and lines. It uses 1K of RAM since it needs to buffer the
entire display but its very fast! The code is simple to adapt to any other microcontroller. You'll
also have to install the Adafruit GFX graphics core library at this github
repo (http://adafru.it/aJa) and install it after you've gotten the OLED driver library.
UG-2864HSWEG01 (http: //adafru.it/aJI) Datasheet
UG-2864HSWEG01 (http: //adafru.it/aJJ) User Guide
SSD1306 (http://adafru.it/aJK) Datasheet
GitHub repo for 128x32 SPI display PCB (http://adafru.it/aJL)
GitHub repo for 128x64 0.96" display PCB (http://adafru.it/aJM)
© Adafruit
Industries
http://learn.adafruit.com/monochrome-oled-breakouts Page 20 of 22

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Adafruit SSD1306 and is the answer not in the manual?

Adafruit SSD1306 Specifications

General IconGeneral
Display TypeOLED
InterfaceI2C or SPI
Display ControllerSSD1306
Resolution128 x 64
Screen Size0.96 inch
ColorMonochrome
Operating Voltage3.3V or 5V
Viewing Angle160 degrees
Pixel ColorWhite
