Adam A5 User Manual

11
English
ANALOG INPUTSTEREO LINK
CONTROLS
UNBALANCED
INPUT OUTPUT
UNBALANCED BALANCED
ANALOG INPUTSTEREO LINK
CONTROLS
UNBALANCED
INPUT OUTPUT
UNBALANCED BALANCED
5. Speaker Adjustment
Room EQs
Whereas the ‘Tweeter Level’ raises or lowers the overall signal going to the
tweeter, the ‘Room EQs allow gradual adjustment of a specific frequency
band from a certain fixed point (Hi EQ above 6 kHz, Lo EQ below 150 Hz
in this case). The given dB values occur at 30Hz and 15kHz. We show five
curves; however, the controls can be changed continuously (see figure 10 &
11).
fig. 10:
ROOM EQ >6 kHz
forthehighfrequencies
above6kHz
fig. 11:
ROOM EQ <150 Hz
forthelowfrequencies
below150Hz
5.3

Adam A5 Specifications

General

Brand	Adam
Model	A5
Category	Speakers
Language	English
