Adam A5 User Manual

16
12. Technical Data
A5. Active Multimedia/Studio Monitor
Tweeter ART Tweeter
Velocity transfer ratio 4:1
Equivalent diaphragm ø 56 mm
/ 2“
Woofer 145 mm / 5.5“
Woofer material Carbonsandwich
Built-in amplifiers 2 (Class 1)
Woofer channel
1/2
25 W / 40 W
Tweeter channel
1/2
25 W / 40 W
Control Panel
Input Sensitivity -∞ to +10 dB
Low shelve > 6 kHz ± 6 dB
High shelve < 150 Hz ± 6 dB
Tweeter gain ± 4 dB
General Data
Frequency response 55 Hz - 35 kHz
THD >80 Hz ≤ 1,5%
SPL with sine wave 100 Hz to 3 kHz in 1m ≥ 101 dB
Max. peak acoustic output in 1m per pair ≥ 110 dB
Crossover frequency 2.200 Hz
Input XLR / RCA
Input impedance 10 kΩ
Weight 5 kg / 11 lb.
Magnetically shielded yes
Height x Width x Depth 285 x 172 x 200 mm / 11“ x 7“ x 8“
Warranty 5 years
Operating temperature 0° C bis 40° C (32° F bis 104° F)
Storage temperature -30° C bis 70° C (-22° F bis 167° F)
Humidity Max. 90 % not condensing
1=longtermIEC265-8-Wrms/10min
2=nominalIEC265-8=PeakPower5µsec
3=payattentiontotheselectedvoltageontherearsideofthespeaker
